AirDog FP-100 Lift Pump (2001-2010)**

This is the AirDog I FP-100-4G fuel system for the 2001-2010 Chevy/GMC Duramax 6.6L. This diesel lift pump mounts to the frame rail using the supplied sandwich plate mounting system. This system utilizes the factory suction port in the fuel module for suction and plugs into the factory fuel line on the pressure side to supply fuel to the CP3 injection pump. The return is sent back to the tank through a filler neck tee. This is one of the easiest fuel systems to install. This is a 100GPH (Gallon Per Hour) lift pump system. Check out our installation manual for a list of parts that are included with this kit.

The AirDog 100GPH lift pump will solve the infamous P0087 & P1093 low fuel rail pressure codes by supplying your CP3 injection pump with fuel, rather than your injection pump doing most of the work pulling the fuel up from the tank. This positive supply of purified fuel being fed to your CP3 will also add performance, throttle response, and longevity to your vehicle. Due to extra stress on your fuel system from either high mileage and/or additional performance modifications, like a tuner or larger injectors, your injection pump can become weak over time. This may result in a drop of performance, reliability, and fuel economy. The supplied water separator (WS100) and fuel filter (FF100-2), that mount to the pump, filter your fuel down to a 2 micron rating, which surpasses the stock fuel filter system capability.

This AirDog 100GPH is recommended for Duramax trucks that have a stock to a mildly upgraded fuel system (meaning mild or stock injectors, injection pump, and tuning). See How To Choose A Lift Pump. Backed by a lifetime warranty.irDog FP-100 Fits 2001-2010 6.6 GM Diesel w/ Quick Disconnect Lines (Preset @8-10psi)

AirDog® Features
•Small & Compact: Only 7"L X 10'T X 3.2"W
•Single Piece Pump Body: Replaces the old 3 piece pump design reducing the number of parts, unit size, and weight. This results in a sleek, low profile pump assembly and eliminates the need for leaky, messy gaskets!
•Mounts to frame: No Drilling required!

AirDog® Installation Kit

All-Inclusive Installation Kit includes:
•Relay Control Wiring Harness
•1/2" Suction Tube (when required)
•All Fuel Fittings Required
•Mounting Hardware
•1/2" Fuel Lines W/ OEM Style Quick Connect Fittings
•AirDog® Bracket & Spacer
•Plastic Ties
•Installation Manual
